Endolaser 422
Endolaser 422
The Endolaser 422 is an advanced and modern designed unit for laser therapy with interchangeable laser probes. Laser therapy, also known as photobiomodulation, low level laser therapy (LLLT), cold laser therapy and laser biostimulation, is an effective method for:
- Pain management
- Wound healing
- Soft tissue injury treatment
- Nerve regeneration
- Skin treatment (esp. for Acne)
- Cosmetic regeneration
Laser is applied to the anatomical region of interest by means of a diode probe. This application can be static and very localized or dynamic for larger regions. In general a treatment only takes a few minutes. This effectiveness and the short application time make laser therapy with the Endolaser 422 a valuable part of a complete treatment session
LASERTHERAPY
Also called LLLT (Low Level Laser Therapy) or Soft Laser, is a form of light therapy in which the concentrated intensity of the bundled light can lead to effective tissue improvement.
TECHNICAL SPECIFICATIONS
Mains voltage: 230 Vac 50-60Hz ±15% 115 Vac 50-60Hz ±15%
Max. Power consumption: 15 VA
Double fuse protection: 250 mA Rit 5x20 mm
Plug for Interlock/safety key
(contacts normally closed) 6 contact DIN plug
Backlit LCD Display, to visualize and control
operating parameters: graphic 240x128 pixel
Programmable treatment time: up to 60 minutes
Diode Laser Wave length for
25, 100, 400mW pulse diode: 905 nm
Diode Laser Wave length for
500 mW continuous laser diode: 808 nm
Laser classification according
to EN-60825-1: 3B
MPE (Maximum permissible exposure): 5032.06 J . m -2
AEL (Accessible emission limit): 77.1 mW (class 3B limit)
Divergence: 107 mrad
NOHD (Nominal ocular
hazard area) direct light: 2.89 meters
NOHD diffused light: 0.00 meter
IR radiation sensor for
external laserprobe: On front panel
Programmable impulse frequency: 10-10.000 Hz
Duty Cycle, only available
with continuous laser diodes: 10-9900 Hz
Independent output channels: 2
Pre-programmed protocols: 82
Free programmable positions: 50
External dimensions (lxhxd): 29x28x11,5 cm
Weight of machine body: 3,2 kg
STANDARD ACCESSORIES
3444290 Mains cable 230V-EUR
1422815 Protective goggles Endolaser 422-2x
1422750 Operating manual Endolaser 422
